DirectLaser MP1 Roll-To-Roll Laser Cutting Equipment For Electronic Metal Materials
New automatic laser cutting system replace corrosion process for making metal precision parts. MP1 laser cutting accuracy is very high and it has no side erosion caused problems. It could provide very good size and shape consistency. With the features of environmentally friendly, flexible process, easy integration into a fully automated continuous production mode, the DirectLaser M1 could be a perfect metal micro processing equipment in the future.
Features
Environmental clean production
Laser direct structure
Wide range of applicable
Automatic feeding and unloading
Product parameters
Technical data | DirectLaser MP1 |
Machinable material | Stainless steel, copper, aluminum |
Max. material thickness | 3mm |
Max. width | 400mm |
Max.working area | 400mm x 400mm |
Power requirement | 380VAC/16A, 3kW |
Dimension（W x H x D） | 1,400mm x 1,250mm x 1,550mm |
Weight | 1,200kg |
| Configuration and options | DirectLaser MP1 |
Data processing software | CircuitCAM 7 Pro |
Automatic feeding | Optional |
